2007 Harley Ultra Classic FLHTCU: Specs and Known Problems

The short answer

The 2007 Electra Glide Ultra Classic (FLHTCU) was the first Ultra with the 1,584cc Twin Cam 96 and the six-speed Cruise Drive gearbox. It came with an 80-watt Harman/Kardon Advanced Audio system, CB, intercom and cruise control for an MSRP of $20,195. ABS, electronic throttle and a 6-gallon tank arrived for 2008. The main things to check are the compensator, the charging system and the radio.

Jump to a section
2007 Harley Ultra Classic FLHTCU: Specs and Known Problems

It is 5 a.m. at a gas station outside Rapid City. Two riders fuel up side by side, one on a brand-new bagger with a giant touchscreen, the other on an Ultra Classic that rolled off the line in 2007. The old one has more miles on its clock than some cars ever see. Its owner hits the starter, the 96 settles into a lumpy idle, the Harman/Kardon crackles to life with the same classic rock station, and he is gone before the new guy has paired his phone.

That is the case for the 2007 Ultra Classic in one scene. It was the first Ultra with the Twin Cam 96 and the six-speed gearbox, it came loaded, and you can buy a good one today for a fraction of a new bagger. Here are the full specs, what changed that year, the problems to check for, and how it compares with a 2008.

2007 Ultra Classic Specifications

Harley’s model code for the Electra Glide Ultra Classic is FLHTCU, and that is the code you will see on titles, parts listings and service manuals. The numbers below come from Motorcycle.com’s 2007 Ultra Classic spec sheet and Motorcyclist’s 2007 FLHTCU listing.

Spec2007 FLHTCU
EngineTwin Cam 96, rubber-mounted, air-cooled 45-degree V-twin
Displacement1,584cc (96 ci)
Bore x stroke3.75 x 4.375 in (95.3 x 111.1 mm)
Compression9.2:1
Fuel systemElectronic Sequential Port Fuel Injection (ESPFI)
Torque125.5 Nm (about 92.6 lb-ft) at 3,500 rpm per Motorcycle.com
TransmissionSix-speed Cruise Drive
Final driveBelt
Wheelbase63.5 in
Seat height27.3 in laden per Motorcycle.com (about 30.7 in unladen on some spec sheets)
Ground clearance5.1 in
Length98.3 in
Fuel capacity5.0 gal
Dry weight808 lb
Wet weight840 lb
BrakesDual front discs, single rear disc, 11.5 in, no ABS
Front tireDunlop MT90B16 72H
Rear tireDunlop MU85B16 77H
Audio80-watt Harman/Kardon Advanced Audio (CD, AM/FM, WB, MP3), CB, intercom
Other standard kitElectronic cruise control, air-adjustable rear suspension, King Tour-Pak, hard saddlebags
MSRP (2007)$20,195

A note on the torque figure. Motorcycle.com lists 125.5 Nm at 3,500 rpm. Harley’s 2007 Touring owner’s manual lists 93 ft-lb at 3,000 rpm. They are close, and both are factory-style numbers rather than rear-wheel dyno results. Use the manual figure if you need an official number.

Why 2007 Was a Big Year

For Harley’s Touring line, 2007 was a real step, not a trim update. The Twin Cam 96 replaced the Twin Cam 88 as the standard Big Twin engine, and the six-speed Cruise Drive became standard alongside it. Motorcyclist’s listing for the FLHTCU calls out both as new for 2007.

More stroke, more pull. The 96 kept the 88’s 3.75 inch bore and stretched the stroke from 4.0 to 4.375 inches. On a bike that weighs 840 pounds wet before you pack it, the extra low-end torque matters more than any top-end number. Our Twin Cam 96 engine guide covers the engine in depth.

Sixth gear. The Cruise Drive six-speed added a tall top gear for highway cruising. At interstate speeds the engine turns fewer revs than a five-speed Ultra, which cuts vibration and helps fuel economy on long days.

Hydraulic cam chain tensioners. This is the one most buyers miss. Law Abiding Biker’s tensioner breakdown explains that the spring-loaded tensioner shoes that wore out on 1999-2006 Twin Cams were replaced on 2007 and later engines by oil-fed hydraulic tensioners with redesigned shoes. The shoes are still wear parts, but the TC88 horror stories do not transfer directly to a 2007.

The Audio System

The Ultra was the top of the Touring range, and the stereo showed it. Motorcyclist lists an 80-watt Harman/Kardon Advanced Audio System with CD, AM/FM, weather band and MP3, plus a CB radio, rider-to-passenger intercom and passenger audio controls. Lesser 2007 Touring models got a 40-watt version.

It was good for its day. By modern standards it is quiet at highway speed, has no Bluetooth, and the CD player has not aged well. Common complaints from owners include disc errors, units that power on but lose sound, and intermittent cutouts. Harley treated the head unit as a sealed part, so repairs usually mean a specialist or a replacement.

You have three choices: keep it original, upgrade the speakers and amp while keeping the Harman/Kardon head unit, or replace the head unit with a plug-in unit made for 1998-2013 Touring bikes. Our guide to the best Harley stereo systems goes through each path for this era.

Known Problems on the 2007 Ultra Classic

No 17-year-old bagger is perfect. These are the issues that come up most often with 2007 Touring bikes. Diagnose by testing and inspection, not by noise alone.

Compensator

The compensator is the spring-loaded sprocket on the engine side of the primary drive that softens the V-twin’s torque pulses. On 2007-era Twin Cam 96 tourers, it is the most talked-about weak spot. It Still Runs’ compensator diagnosis guide lists the symptoms: a loud clang at start-up, trouble finding first or neutral, and a gravel sound from the front of the primary around 2,200 rpm. It also makes the key point: the only way to know for sure is to pull the primary cover and look.

Owners on the Harley Davidson Forums compensator thread describe the fixes people use: Harley’s later upgraded compensator kits, the unit from later Touring models, or an aftermarket eliminator or aftermarket compensator. There was no recall. If a seller has records of a compensator upgrade, that is worth money to you.

Charging system

The stator and voltage regulator on bikes of this age can fail, and a failing one can take the other with it. Symptoms include a battery that will not stay charged, dim or flickering lights, and a voltmeter reading outside its normal range. Test the battery first, then the charging output with the factory procedure before you buy parts.

Heat

Air-cooled Big Twins run hot in slow traffic, and the rear cylinder sits right under the rider. Heat you can feel on your right leg in July is normal. Pinging, check engine lights or a big change from how the bike used to run are not. Our Harley diagnostic codes list helps you read any trouble codes it throws.

2007 Harley Ultra Classic FLHTCU: Specs and Known Problems

First-gear clunk

The six-speed goes into first with a solid clunk, especially when cold. That is how these gearboxes feel, and owners argue about it endlessly. A clunk that gets worse, grinding or jumping out of gear is a different story and needs a proper look.

Everything that ages

Fork seals, brake fluid, wheel bearings, the belt, tires and rubber fuel lines all age whether the bike is ridden or not. On a low-mile bike that sat for years, tires and fluids are the first spend. Check the tire date codes, not just the tread.

A “garage queen” Ultra with 9,000 miles that sat for a decade can need more work than a 60,000-mile bike that was ridden and serviced every season. Miles are not the whole story. Maintenance is.

2007 vs 2008 Ultra Classic

If you are shopping for a 2007, you will be looking at 2008s too. Motorcycle News’ report on the 2008 Touring updates lists the changes:

  • Optional ABS across the Touring range
  • Electronic Throttle Control, Harley’s first fly-by-wire throttle
  • A new generation of cruise control, standard on the Ultra Classic, Road King Classic and Street Glide
  • A bigger fuel tank, up from 18.9 to 22.7 liters (5 to 6 gallons)

The engine and gearbox carried over. So the choice is simple: if you want ABS and an extra gallon of range, pay the extra for a 2008 with ABS fitted. If you want the simplest electronics and a mechanical throttle cable, the 2007 is the last Ultra with one.

Buying a Used 2007 Ultra Classic

Price. A 2007 Ultra is now a budget touring bike. Check condition-graded values for the exact model on J.D. Power’s 2007 FLHTCU values page and look at sold prices rather than asking prices. Condition, miles, records and accessories swing it a lot.

Run the VIN. Confirm the model, year and engine match the title. Our Harley VIN decoder shows you what each digit means.

Start it cold. Listen for a clang from the primary on start-up and ask when the compensator was last looked at.

Check the charging voltage at idle and at about 2,000 rpm with the lights on.

Test every switch. Radio, CB, intercom, cruise, heated grips if fitted, every light. Electrical fixes on a fully loaded tourer add up fast.

Look at the records. Oil changes, primary and transmission fluid, brake fluid and any compensator or charging work. A thick folder is worth more than a low odometer.

Check for crash damage. Fairing mounts, lower legs, bag guards and the bottom of the saddlebags tell you if it has been down.

Honest take: a well-kept 2007 Ultra is one of the best-value long-distance Harleys you can buy. It has the engine and gearbox the 2006 and earlier bikes wish they had, and none of the complexity of the newer infotainment bikes.

Heading out on a long one? Our biker hoodies are made for cold mornings at the pump, and our biker tees for the afternoon when the heat hits.

Where the 2007 Ultra Sits in Harley History

The 2007 Ultra is the middle of the Twin Cam story. The 88 came before it, the 103 followed, and the Milwaukee-Eight replaced the whole family for 2017. Later chassis updates and the 2014 switch from Harman/Kardon to Boom! Box infotainment changed the bikes again. For how every Harley engine family fits together, read our Harley-Davidson history guide.

Sources

For the wider story of every engine generation from the V-twin to the Milwaukee-Eight, see our Harley-Davidson history guide.

Frequently Asked Questions

What engine does the 2007 Harley-Davidson Ultra Classic have?

The rubber-mounted Twin Cam 96: an air-cooled 45-degree V-twin of 1,584cc (96 ci) with a 3.75 x 4.375 inch bore and stroke, 9.2:1 compression and Electronic Sequential Port Fuel Injection. 2007 was the first year of the 96 across Harley's standard Big Twins.

How much does the 2007 Harley-Davidson Ultra Classic weigh?

Motorcycle.com lists 808 lb dry and 840 lb wet. Loaded with a rider, passenger and luggage, you are well past half a ton, so plan your parking lot moves.

What stereo does the 2007 Ultra Classic have?

An 80-watt Harman/Kardon Advanced Audio System with CD, AM/FM, weather band and MP3 support, plus CB radio and rider-to-passenger intercom. Other 2007 Touring models got a 40-watt version.

Does the 2007 Ultra Classic have ABS?

No. Optional ABS came to Harley's Touring range for the 2008 model year, along with the first electronic throttle and a larger fuel tank.

What was the original MSRP of the 2007 Harley-Davidson Ultra Classic?

$20,195, according to Motorcycle.com's spec listing.

What are the common problems on a 2007 Ultra Classic?

The ones owners talk about most are the primary compensator (clunking or a gravel sound at startup), charging system faults in the stator and regulator, heat from the rear cylinder in traffic, and Harman/Kardon radio failures. The 2007 cam chain tensioners are hydraulic, so the TC88 tensioner problem is much less of a worry.

Is a 2007 Ultra Classic a good used buy?

It can be. The 96 and six-speed make it a big step up from 2006 and earlier Twin Cam tourers. Buy on condition and records, check the compensator and charging system, and decide whether you want to pay more for a 2008 with ABS and electronic cruise.
